PT510
DESCRIPTION
Machine for vertical cleaning of wooden panels and boards of all measures in height between 100 ÷ 500 mm. The release of disarming liquid is applied by means of an external pump with double filtering system to avoid blockages. The rollers are grooved to facilitate the advancement of the panel. A double series of oscillating scrapers allows perfect cleaning of the edges and ensures excellent adhesion on the side surfaces even in the presence of deformations in the wood. Adjustable scraping pressure to suit your cleaning needs.
| Boards and panels work thickness (mm) | 10÷50 |
| Max working height of boards and panels (mm) | 100÷500 |
| Hourly production (m/h) | about 800 |
| Tub capacity (l) | 30 |
| Sound emission level (dB) | 74 |
| Work position lenght (mm) | 2480 |
| Dimensions (LxWxH in mm) | 1280x820x1250 |
Handwheel to adjust the height of panels and boards
Side handwheel to adjust the thickness of panels and boards
Outside washing chamber with inlet and outlet spatulas to reduce the loss of disarming liquid
Front and rear movable guide to reduce transport dimensions
Plastic tub, for the collection of disarming liquid, removable for easier cleaning
STANDARD KIT
Technical documentation and CE certificate
