TP70/90 foot pedal system
TP70/90 foot pedal system - Image 2

TP70/90 foot pedal system

Code Engine Type Power Weight (kg)

230V-50Hz Electric Single-Phase

2,2 kW – 3 HP

 115

400V-50Hz Electric Three-Phase

2,2 kW – 3 HP

 118

400V-50Hz Electric Three-Phase

3 kW – 4 HP

 121

230V-50Hz Electric Single-Phase

3 kW – 4 HP

 182

400V-50Hz Electric Three-Phase

4kW – 5,5 HP

 187
Data sheet

DESCRIPTION
The MAKER pendular line sawing machine model TP70 with belt drive and foot pedal system is ideal for vertical cuts as well, as the material can be handled with both hands. It has a steel sheet frame with a built-in 40-liter tub and immersion pump for water recycling; manual advancement of the carriage which runs on watertight bearings; manual adjustment of the cutting height or progressive with foot pedal system. The TP90 model always belt driven with foot pedal system is used on the construction site for superior work performance in terms of power and cutting height.

TP70 foot pedal systemTP90 foot pedal system
Max blade diameter (mm)400600
Blade hole diameter (mm)25,425,4
Max cutting depth (mm)150240
Cutting length (mm)700450
Sheet tub capacity (l)4570
Sound emission level (dB)112112
Dimensions (LxWxH in mm)1150x650x15001400x700x1600

Belt drive
Handle to adjust the blade height for cutting
Water cooling system on the front of the blade to avoid any risk of overheating
Rear protection
Splash guard mat
Galvanized and sliding worktop
360° adjustable square
Immersion electric pump
Prolonged guide that also acts as a handle
Foot pedal system
OPTIONAL
Trolley with tilt from 0 to 45°
Blade guard Ø 450 mm (H=175 mm)
Blade guard Ø 500 mm (H=190 mm)
STANDARD KIT
Diamond blade, technical documentation and CE
